| Technical Specifications | |
|---|---|
| Type | Strain gauge |
| Capacity | 1000 Bar |
| Rated Output (mV/V) | 2.0002 |
| Non-linearity (% FS) | 0.020 |
| Hysteresis (% FS) | 0.020 |
| Repeatability (% FS) | 0.020 |
| Creep (% FS/30 min) | 0.019 |
| Temp. effect on zero (% FS/10°C) | 0.016 |
| Temp. effect on span (% FS/10°C) | 0.019 |
| Zero balance (% FS) | ±1 |
| Input impedance (Ω) | 350 ± 5 |
| Output impedance (Ω) | 350 ± 5 |
| Insulation resistance (MΩ) | ≥ 5000 (50 V DC) |
| Excitation voltage (V DC) | 9~12 |
| Allowed excitation voltage (V DC) | 5~18 |
| Compensated temp. Range (°C) | 10°C~+40°C |
| Operating temp. Range (°C) | -20°C~+55°C |
| Safe overload (% FS) | 120 |
| Ultimate Overload (% FS) | 150 |
